Picture/Ref.DescriptionApplication
Brake drum:171 501 615 A
171 501 615 A

Brake drum

Rear Axle
Height
: 74.5 mm
Inner Brake Drum Height : 38.5 mm
Diameter : 212 mm
Drum Diameter : 180 mm
Center Diameter 1 : 39.8 mm
Center Diameter 2 : 50.2 mm
Pitch Circle Diameter : 100 mm
Num. of holes : 4

SEAT CORDOBA Vario (6K5)
VOLKSWAGEN SCIROCCO (53B)
VOLKSWAGEN SCIROCCO (53)
VOLKSWAGEN SANTANA (32B)
VOLKSWAGEN POLO Box (86CF)
VOLKSWAGEN POLO Box (6NF)
More...
Brake drum:191 501 615 A
191 501 615 A

Brake drum

Rear Axle
Height
: 81 mm
Inner Brake Drum Height : 50 mm
Diameter : 240 mm
Drum Diameter : 200 mm
Center Diameter : 39.8 mm
Pitch Circle Diameter : 100 mm
Num. of holes : 4

VW (SVW) SANTANA 2000
AUDI FOX (80, 82, B1)
For use:
AUDI、SEAT、SKODA、VW (SVW)、VOLKSWAGEN
Brake Disc:321 615 301 C
321 615 301 C

Brake Disc

Front Axle
Height : 39 mm
Diameter : 239 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 20.0 mm
Minimum Thickness : 18 mm
Num. of holes : 4
Solid or Vented : V
Weight : 3.8 kg

VW (SVW) GOL
SEAT CORDOBA Vario (6K5)
VOLKSWAGEN VENTO (1H2)
VOLKSWAGEN SCIROCCO (53B)
VOLKSWAGEN SCIROCCO (53)
VOLKSWAGEN SANTANA (32B)
More...
Brake Disc:8N0 615 601 B
8N0 615 601 B

Brake Disc

Rear Axle
Height
: 36.6 mm
Diameter : 256 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 22.0 mm
Minimum Thickness : 20 mm
Num. of holes : 5
Solid or Vented : V
Weight : 4.4 kg

VW (FAW) GOLF
VW (FAW) BORA
VW (FAW) BORA HS Hatchback
AUDI TT (8J3)
VOLKSWAGEN BEETLE (9C1, 1C1)
VOLKSWAGEN GOLF IV Variant (1J5)
More...
Brake Disc:8L0 615 301
8L0 615 301

Brake Disc

Front Axle
Height : 34.5 mm
Diameter : 312 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 9
Solid or Vented : V
Weight : 7.9 kg

VW (FAW) GOLF
VW (FAW) BORA
VW (FAW) BORA HS Hatchback
VOLKSWAGEN POLO Saloon (9A4)
VOLKSWAGEN POLO (9N_)
VOLKSWAGEN BEETLE (9C1, 1C1)
More...
Brake Disc:8E0 615 601 D
8E0 615 601 D

Brake Disc

Rear Axle
Height : 39.8 mm
Diameter : 255 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 11.9 mm
Minimum Thickness : 10 mm
Num. of holes : 10
Solid or Vented : S
Weight : 3.8 kg

AUDI (FAW) A4 Saloon (8EC, B7)
AUDI (FAW) A4 Saloon (8E2, B6)
AUDI A4 Avant (8ED)
AUDI A4 (8EC, B7)
AUDI A4 Convertible (8H7, B6, 8HE, B7)
AUDI A4 Avant (8E5, B6)
More...
Brake Disc:895 615 601 A
895 615 601 A

Brake Disc

Rear Axle
Height : 39.7 mm
Diameter : 245 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.2 kg

AUDI 80 Avant (8C, B4)
AUDI 80 (8C, B4)
AUDI COUPE (89, 8B)
For use:
AUDI
Brake Disc:8E0 615 301 B
8E0 615 301 B

Brake Disc

Front Axle
Height : 46.3 mm
Diameter : 280 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 22.0 mm
Minimum Thickness : 20 mm
Num. of holes : 5
Solid or Vented : V
Weight : 6.2 kg

AUDI (FAW) A4 Saloon (8EC, B7)
AUDI (FAW) A4 Saloon (8E2, B6)
SEAT EXEO ST (3R5)
SEAT EXEO (3R2)
VOLKSWAGEN PASSAT Variant (3B5)
VOLKSWAGEN PASSAT (3B2)
More...
Brake Disc:8D0 615 601 B
8D0 615 601 B

Brake Disc

Rear Axle
Height : 83.6 mm
Diameter : 245 mm
Centering Diameter : 45.2 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 5.4 kg

AUDI (FAW) 200 (447)
AUDI A4 Avant (8D5, B5)
AUDI A4 (8D2, B5)
For use:
AUDI、AUDI (FAW)
Brake Disc:8D0 615 601 A
8D0 615 601 A

Brake Disc

Rear Axle
Height : 48 mm
Diameter : 245 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.4 kg

VOLKSWAGEN PASSAT Variant (3B6)
VOLKSWAGEN PASSAT Variant (3B5)
VOLKSWAGEN PASSAT (3B3)
VOLKSWAGEN PASSAT (3B2)
AUDI A4 Avant (8D5, B5)
AUDI A4 (8D2, B5)
More...
